Product Name : AL-100
Product Description
A RAIN RFID UHF reader with low power consumption (+25dBm) wireless Bluetooth handheld, reading distance up to 3M (Dependent on Tag), supports Bluetooth, HID interface, and provides Android/ iOS SDK. It is suitable for inventory applications, such as asset inventory, document inventory, commodity inventory, and patrol inventory applications, and is a trigger handle RFID reader.
PRODUCT AL-100
DIMENSION(LXWXD) 188mm X 73mm X 18mm
Weight 155g
Battery Pack
  • 3.6V Lithium Polymer; 4watt hours
  • 1515mAh
  • rechargeable
  • non-Removable
Frequency region US ,TW ,VM
Transmit Power 0 to +25dBm (1dBm/per step)
AIR PROTOCOLS EPC Global UHF Class 1 Gen2 / ISO 18000-6C
communication
  • Bluetooth: ® Version 4.2
  • Bluetooth range: 8m(26ft)
  • Micro USB: HID Keyboard
Read Range 3m(16ft)
Write Range 1m(10ft)
Operating Temperature -10ºC to +40ºC
Charging Temperature 5ºC to +40ºC
Storage Temperature -40ºC to +60ºC
umidity 5% to 85% non-condensing
AL-100 Datasheet DOWNLOAD
